RU FRZ850 465P

Item number: 100105

RU FRZ850 465P is a large-volume cryo-freezer for biobanking and automated sample storage in the LN₂ vapour phase.

Technical Data

• LN₂ Capacity: approx. 890 l
• LN₂ under vapour phase platform: approx. 165 l
• Neck/Open width: 465 mm
• Usable internal height: approx. 765 mm
• Internal diameter: approx. 1113 mm
• External diameter: approx. 1190 mm
• Total height: approx. 1600 mm
• Door width: approx. 1210 mm
• Weight empty: approx. 400 kg
• Weight in vapour phase operation: approx. 1112 kg

Maximum storage capacity – depending on rack configuration

• 2-ml cryovials: up to 42900
• Large racks: 32 × CFC-13-2
• 5-ml cryovials: up to 15552
• 5-ml racks: 32 racks, 6 boxes per rack
• 25-ml blood bags: up to 2996
• 50-ml blood bags: up to 1904
• 250-ml blood bags: up to 832
• 500-ml blood bags: up to 464
• 200-ml blood bags: up to 576
• 700-ml blood bag: up to 336

Series functions

• Automatic LN₂ filling: Yes
• Operation: Touchscreen
• Data / Interfaces: USB and RS485
• Additional functions: De-misting and foldable step
• Optional: Backup battery, vacuum hose, racks, Wi-Fi/Cloud connection

Availability: Available to order – delivery time on request.

Technical specifications are based on the currently available manufacturer documents. Please confirm design, compatibility, and scope of delivery based on the current data sheet or offer before ordering.
