RU FRZ550 445P

Article number: 100102

RU FRZ550 445P is a large-volume cryo-freezer for biobanking and automated sample storage in the LN₂ vapour phase.

Technical Data

• LN₂ Capacity: approx. 588 l
• LN₂ under vapour phase platform: approx. 125 l
• Neck/Opening Width: 445 mm
• Usable Internal Height: approx. 590 mm
• Internal Diameter: approx. 1012 mm
• External Diameter: approx. 1090 mm
• Total Height: approx. 1400 mm
• Door Width: approx. 1140 mm
• Weight Empty: approx. 310 kg
• Weight in Vapour Phase Operation: approx. 750 kg

Maximum Storage Capacity – depending on rack configuration

• 2-ml Cryovials: up to 28000
• Large Racks: 24 × CFC-10-2
• 5-ml Cryovials: up to 9720
• 5-ml Racks: 24 racks, 5 boxes per rack
• 25-ml Blood Bags: up to 2448
• 50-ml Blood Bags: up to 1488
• 250-ml Blood Bags: up to 588
• 500-ml Blood Bags: up to 396
• 200-ml blood bag: up to 348
• 700-ml blood bag: up to 204

Standard features

• Automatic LN₂ filling: Yes
• Operation: Touchscreen
• Data / Interfaces: USB and RS485
• Additional features: De-misting and foldable step
• Optional: Backup battery, vacuum hose, racks, Wi-Fi/Cloud connection

Availability: Available to order – delivery time on request.

Technical specifications are based on the currently available manufacturer documents. Please confirm design, compatibility, and scope of delivery against the current data sheet or offer before ordering.
